| Technical Data Sheet | ||
| ● | Way | 4 |
| ● | Frequency Range | 6～18GHz |
| ● | Insertion Loss | ≤7.2dB (Contain theory loss 6.0 dB) |
| ● | VSWR | ≤1.5:1 |
| ● | Isolation | ≥16dB |
| ● | Amplitude Balance | ±0.5dB max |
| ● | Phase Balance | ±5º max |
| ● | Impedance | 50 ohms |
| ● | Power Handling | Forward ≤10Watt；Reversed ≤0.5Watt |
| ● | Surface Finish | Black Paint |
| ● | Connectors | SMA-Female |
| ● | OperatingTemperature | -25℃to+65℃ |
