| Technical Data Sheet | |||
| S/N | Item | RX | TX |
| ● | Pass Band Frequency | 1350 ~ 1500MHz | 1650 ~ 1800MHz |
| ● | Pass Band Insertion Loss | ≤1.0dB | ≤1.0dB |
| ● | VSWR | ≤1.30:1 | ≤1.30:1 |
| ● | Stop Band Attenuation | ≥80dB @ 1650 ~ 1800MHz | ≥80dB @ 1350 ~ 1500MHz |
| ● | Impedance | 50 Ohms | |
| ● | Average Power | 20W Max. | |
| ● | Connectors | N-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -40℃ ~ +70℃ | |
| ● | Dimensions | 100*60*40mm | |
| ● | Working Environment | Indoor | |
| Test Curve | |||
