Technical Data Sheet
●	Frequency Range	1.0 ~ 6.0GHz
●	Phase Difference	90°
●	Nominal Split	3.01dB
●	Insertion Loss	≤0.7dB
●	VSWR	≤1.25:1
●	Amplitude Balance	≤±0.6dB
●	Phase Balance	≤±5.0°
●	Isolation	≥20dB
●	Impedance	50 Ohms
●	Power Handling	Average: 50W ; Peak: 1000W
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
Test Curve
