Technical Data Sheet
●	Center Frequency(F0)	7.0GHz
●	Pass Band Frequency	5.0 ~ 9.0GHz
●	Pass Band Insertion Loss	≤1.5dB
●	Pass Band VSWR	≤1.7:1
●	Stop Band Rejection	≥40dB @ DC ~ 4.0GHz	≥40dB @ 10 ~ 12GHz
●	Impedance	50 Ohms
●	Power	2W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
