Technical Data Sheet
●	Center Frequency(F0)	4200MHz
●	Pass Band Frequency	3650 ~ 4750MHz
●	Pass Band Insertion Loss	≤1.3dB
●	Pass Band Ripple	≤0.7dB
●	Pass Band Return Loss	≥20dB
●	Stop Band Rejection	≥30dB @ DC ~ 3500MHz	≥30dB @ 4900 ~ 13000MHz
●	Impedance	50 Ohms
●	Power Handling	5W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
