Technical Data Sheet
●	Center Frequency(F0)	930MHz
●	Pass Band Frequency	900 ~ 960MHz
●	Pass Band Insertion Loss	≤1.5dB
●	Pass Band Ripple	≤0.7dB
●	Pass Band VSWR	≤1.22:1
●	Stop Band Rejection	≥70dB @ DC ~ 850MHz	≥70dB @ 1010 ~ 2200MHz
●	Impedance	50 Ohms
●	Power	100W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
