Technical Data Sheet
●	Center Frequency(F0)	9300MHz
●	Pass Band Frequency	9200 ~ 9400MHz
●	Pass Band Insertion Loss	≤0.8dB
●	Pass Band Ripple	≤0.3dB
●	Pass Band VSWR	≤1.2:1
●	Stop Band Rejection	≥55dB @ DC ~ 8765MHz	≥55dB @ 9835 ~ 12000MHz
●	Impedance	50 Ohms
●	Power Handling	50W Max.
●	Connectors	N-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
