Technical Data Sheet
●	Center Frequency(F0)	869.5MHz
●	Pass Band Frequency	824 ~ 915MHz
●	Pass Band Insertion Loss	≤1.5dB
●	Pass Band Ripple	≤0.65dB
●	Pass Band Return Loss	≥23dB
●	Stop Band Rejection	≥60dB @ DC ~ 784MHz	≥60dB @ 955 ~ 3000MHz
●	Impedance	50 Ohms
●	Power Handling	30W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
