Technical Data Sheet
●	Frequency Range	825~850MHz
●	Insertion Loss	≤0.8dB
●	Ripple	≤0.5dB
●	VSWR	≤1.3:1
●	Rejection	≥40dB@DC~775MHz
		≥40dB@900~2000MHz
●	Input Power	20W
●	Port Connectors	SMA-Female
●	Impedance	50 Ω
●	Operating Temp.	-40℃~+85℃
Test Curve
