| Technical Data Sheet | |||
| S/N | Item | Parameters | |
| RX | TX | ||
| 1 | Center Frequency(F0) | 813.5MHz | 858.5MHz |
| 2 | Pass Band Frequency | 806 ~ 821MHz | 851 ~ 866MHz |
| 3 | Pass Band Insertion Loss | ≤1.2dB | ≤1.2dB |
| 4 | VSWR | ≤1.40:1 | ≤1.40:1 |
| 5 | Ports Isolation | ≥60dB @851 ~ 866MHz | ≥60dB@806 ~ 821MHz |
| 6 | Impedance | 50 Ohms | |
| 7 | Average Power | 100W Max. | |
| 8 | Connectors | N-Female | |
| 9 | Surface Finish | Painted Black | |
