| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 12.7GHz | |
| ● | Pass Band Frequency | 12.45 ~ 12.95GHz | |
| ● | Pass Band Insertion Loss | ≤1.35dB (Typical: 1.0dB) | |
| ● | Pass Band Ripple | ≤0.46dB | |
| ● | Pass Band Return Loss | ≥20dB | |
| ● | Stop Band Attenuation | ≥40dB @ DC ~ 12.25GHz | ≥40dB @ 13.15 ~ 26GHz |
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 5W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
