| Technical Data Sheet | ||
| ● | Center Frequency(F0) | 925MHz |
| ● | Pass Band Frequency | 890 ~ 960MHz |
| ● | Pass Band Insertion Loss | ≤1.8dB |
| ● | Pass Band VSWR | ≤1.4:1 |
| ● | Stop Band Rejection | ≥45dB @ 870 ~ 880MHz |
| ● | Impedance | 50 Ohms |
| ● | Power | 100W CW |
| ● | Connectors | N-Female |
| ● | Surface Finish | Painted Black |
| ● | Temperature Range | -20℃ ~ +60℃ |
| ● | Waterproof | IP67 |
| Test Curve | ||
