| Technical Data Sheet | ||
| ● | Way | 8 |
| ● | Frequency Range | 5～12GHz |
| ● | Insertion Loss | ≤10.5dB |
| ● | VSWR | ≤1.6:1 |
| ● | Isolation | ≥16dB |
| ● | Amplitude Difference | ≤±0.6dB |
| ● | Phase Difference | ≤±6° |
| ● | Impedance | 50 ohms |
| ● | Power Handling | Forward: 20W Max. ; Reverse: 0.5W Max. |
| ● | Surface Finish | Painted Black |
| ● | Connectors | SMA-Female |
| ● | Temperature Range | -40℃～+70℃ |
| Test Curve | ||
