| Technical Data Sheet | ||
| ● | Center Frequency(F0) | 39MHz |
| ● | Pass Band Bandwidth | 4.0MHz (37 ~ 41MHz) |
| ● | Pass Band Insertion Loss | ≤1.0dB |
| ● | Pass Band VSWR | ≤1.5:1 |
| ● | Stop Band Rejection | ≥30dB @ F0±12MHz (DC ~ 27MHz , 51 ~ 200MHz) |
| ● | Impedance | 50 Ohms |
| ● | Power Handling | 5.0W Max. |
| ● | Connectors | SMA-Female Removable |
| ● | Surface Finish | The Original Silver Color |
| ● | Temperature Range | -30℃ ~ +70℃ |
| Test Curve | ||
