| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 30MHz | |
| ● | Pass Band Bandwidth | 2.0MHz (29 ~ 31MHz) | |
| ● | Pass Band Insertion Loss | ≤2.0dB | |
| ● | Pass Band VSWR | ≤1.5:1 | |
| ● | Stop Band Rejection | ≥40dB @ DC ~ 23MHz | ≥40dB @ 39 ~ 100MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 1.0W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Nickel Plating or Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
