| Technical Data Sheet | |||
| ● | Center Frequency | 203MHz | |
| ● | Pass Band Frequency | 5MHz (200.5 ~ 205.5MHz) (Design actual bandwidth: ≈40MHz) | |
| ● | Pass Band Insertion Loss | ≤3.0dB @ 200.5 ~ 205.5MHz | |
| ● | Pass Band VSWR | ≤1.5:1 @ 200.5 ~ 205.5MHz | |
| ● | Stop Band Rejection | ≥40dB @ DC ~ 161MHz | ≥40dB @ 256 ~ 550MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 1.0W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Chemical Nickel | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
