| Technical Data Sheet | ||
| ● | Pass Band Frequency | 20～300MHz |
| ● | Pass Band Insertion Loss | ≤3.0dB |
| ● | Pass Band Ripple | ≤2.0dB |
| ● | Pass Band Return loss | ≥10dB |
| ● | Stop Band Rejection | ≥50dB @ DC～15MHz |
| ● | Impedance | 50 ohms |
| ● | Power Handling | ≤0.5W |
| ● | Connectors | SMA-Female |
| ● | Surface Finish | Nickel Plating (Chemical nickel) |
| ● | Operating Temperature | -20℃～+80℃ |
| Test Curve | ||
