| Technical Data Sheet | |||
| S/N | Item | RX | TX |
| ● | Frequency Range | 880～915MHz | 925～960MHz |
| ● | Insertion Loss | ≤1.0dB | ≤1.0dB |
| ● | Ripple | ≤0.8dB | ≤0.8dB |
| ● | Return Loss | ≥18dB | ≥18dB |
| ● | Rejection | ≥60dB@925～960MHz | ≥60dB@880～915MHz |
| ● | Input Power | 50W CW | |
| ● | Operating Temperature | -40℃～+70℃ | |
| ● | Surface Finish | Black Paint | |
| ● | Connectors | N-Female | |
| ● | Dimensions | 168*127*50mm | |
| ● | Working Environment | Indoor | |
| Test Curve | |||
