| Technical Data Sheet | |||
| S/N | Item | RX | TX |
| ● | Center Frequency(F0) | 2615MHz | 2665MHz |
| ● | Pass Band Bandwidth | 2600 ~ 2630MHz | 2650 ~ 2680MHz |
| ● | Pass Band Insertion Loss | ≤1.5dB | ≤1.5dB |
| ● | Pass Band Ripple | ≤0.7dB | ≤0.7dB |
| ● | Pass Band VSWR | ≤1.3:1 | ≤1.3:1 |
| ● | Stop Band Attenuation | ≥50dB @ 2650 ~ 2680MHz | ≥50dB @ 2600 ~ 2630MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power | 30W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Working Environment | Indoor | |
| Test Curve | |||
