| Technical Data Sheet | |||
| S/N | Item | RX | TX |
| ● | Center Frequency(F0) | 1880MHz | 1960MHz |
| ● | Pass Band Frequency | 1850 ~ 1910MHz | 1930 ~ 1990MHz |
| ● | Pass Band Insertion Loss | ≤1.5dB | ≤1.5dB |
| ● | VSWR | ≤1.30:1 | ≤1.30:1 |
| ● | Stop Band Attenuation | ≥50dB @1930 ~ 1990MHz | ≥50dB @ 1850 ~ 1910MHz |
| ● | Impedance | 50 Ohms | |
| ● | Average Power | 100W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Metal Color | |
| ● | Temperature Range | -20℃ ~ +60℃ | |
| ● | Working Environment | Indoor | |
| Test Curve | |||
