| Technical Data Sheet | ||||
| Serial | Parameters | P1 | P2 | P3 |
| 1 | Center Frequency(F0) | 915MHz | 1370MHz | 2250MHz |
| 2 | Pass Band Frequency | 902~ 928MHz | 1350~ 1390MHz | 2240-2260MHz |
| 3 | Pass Band Insertion Loss | ≤2.0dB | ≤2.0dB | ≤2.0dB |
| 4 | Pass Band VSWR | ≤1.4:1 | ≤1.4:1 | ≤1.4:1 |
| 5 | Stop Band Attenuation | ≥40dB @ DC-882MHz | ≥40dB @DC~ 1330MHz | ≥40dB @DC~ 2210MHz |
| ≥40dB @948-2500MHz | ≥40dB @1410~ 3000MHz | ≥40dB @2290~ 4000MHz | ||
| 6 | Iisolation | ≥60dB@902~ 928MHz 1350~ 1390MHz 2240-2260MHz | ||
| 7 | Impedance | 50 Ohms | ||
| 8 | Power | 50W Max. | ||
| 9 | Connectors | N-Female | ||
| Test Curve | ||||
