| Technical Data Sheet | |||
| S/N | Item | RX | TX |
| 1 | Center Frequency (F0) | 832.5MHz | 877.5MHz |
| 2 | Pass Band Frequency | 825～840MHz | 870～885MHz |
| 3 | Pass Band Insertion Loss | ≤1.5dB | ≤1.5dB |
| 4 | Pass Band VSWR | ≤1.3:1 | ≤1.3:1 |
| 5 | Stop Band Rejection | ≥60dB @ 870～885MHz | ≥60dB @ 825～840MHz |
| 5 | Impedance | 50 ohms | |
| 6 | Power Handling | ≤10W | |
| 7 | Connectors | SMA-Female | |
| 8 | Surface Finish | Black Paint | |
| 9 | Port Sign | Port1: ANT ; Port2: RX ; Port3: TX | |
| 10 | Working Environment | Indoor | |
| Test Curve | |||
