| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 50GHz | |
| ● | Pass Band Frequency | 40 ~ 60GHz | |
| ● | Pass Band Insertion Loss | ≤1.3dB | |
| ● | Pass Band Ripple | ≤0.65dB | |
| ● | Pass Band Return Loss | ≥11dB (Typical: 13.5dB) | |
| ● | Stop Band Rejection | ≥80dB @ DC ~ 37.5GHz | ≥10dB @ 61.5 ~ 66GHz |
| ≥35dB @ 37.5 ~ 39GHz | |||
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 5W Max. | |
| ● | Connectors | 1.85mm(V)-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
