| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 40GHz | |
| ● | Pass Band Frequency | 30 ~ 50GHz | |
| ● | Pass Band Insertion Loss | ≤0.85dB | |
| ● | Pass Band Ripple | ≤0.37dB | |
| ● | Pass Band Return Loss | ≥16dB | |
| ● | Stop Band Rejection | ≥80dB @ DC ~ 27.5GHz | ≥10dB @ 51 ~ 56GHz |
| ≥35dB @ 27.5 ~ 29GHz | |||
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 5W Max. | |
| ● | Connectors | 2.4mm(Q)-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
