Technical Data Sheet
●	Stop Band Center Frequency	780.5MHz
●	Stop Band Frequency	758～803MHz
●	Stop Band Attenuation	≥40dB
●	Pass Band Frequency	DC～733MHz & 828～2190MHz
●	Pass Band Insertion Loss	≤0.75dB / ≤1.0dB @ Corners
●	Pass Band VSWR	≤1.5:1 @ DC～733MHz & 828～2000MHz
		≤1.7:1 @ 2000～2190MHz
●	Impedance	50 ohms
●	Power Handling	≤5W
●	Connectors	SMA-Female
Test Curve
