| Technical Data Sheet | ||
| ● | Stop Band Center Frequency | 37MHz |
| ● | Stop Band Frequency | 36 ~ 38MHz |
| ● | Stop Band Attenuation | ≥60dB |
| ● | Pass Band Frequency | DC ~ 30MHz , 45 ~ 150MHz |
| ● | Pass Band Insertion Loss | ≤2.0dB |
| ● | Pass Band VSWR | ≤1.8:1 |
| ● | Impedance | 50 Ohms |
| ● | Power Handling | +15dBm Max. |
| ● | Connectors | SMA-Female |
| ● | Surface Finish | Painted Black |
| ● | Temperature Range | -30℃ ~ +70℃ |
| Test Curve | ||
