| Technical Data Sheet | ||
| ● | Stop Band Frequency | 2.0 ~ 2.5GHz |
| ● | Stop Band Attenuation | ≥40dB |
| ● | Pass Band Frequency | DC ~ 1.6GHz , 3.0 ~ 4.0GHz |
| ● | Pass Band Insertion Loss | ≤1.0dB |
| ● | Pass Band VSWR | ≤1.8:1 |
| ● | Impedance | 50 Ohms |
| ● | Power Handling | 10W Max. |
| ● | Connectors | SMA-Female |
| ● | Surface Finish | Painted Black |
| ● | Temperature Range | -30℃ ~ +70℃ |
| Test Curv | ||
