800W Attenuator

  • 800W RF Coaxial Attenuator DC-4GHz 50DB N,7/16
  • 800W RF Coaxial Attenuator DC-4GHz 50DB N,7/16
800W RF Coaxial Attenuator DC-4GHz 50DB N,7/16800W RF Coaxial Attenuator DC-4GHz 50DB N,7/16

800W RF Coaxial Attenuator DC-4GHz 50DB N,7/16

  • Power：800W
  • frequency:DC-4GHz
  • Attenuation value:50DB
  • Connector：N,7/16
  • Product description: Good heat dissipation, high cost performance ♦ Low VSWR ♦ High precision attenuation ♦ Resistance to pulse ♦ Wide working frequency ♦ Working temperature and 55 ℃ ~ + 125 ℃
  • PDF technical index download
800W Coaxial Attenuato
Technology Manual
Model Number Freq. Range Attenuation Value/Tolerance VSWR Max
30dB 40dB 50dB 60dB /
HXTS800-XX-1-X DC-1GHz / ±1.0 ±1.0 ±1.5 / 1.2
HXTS800-XX-2-X DC-2GHz / ±1.25 ±1.5 ±2.0 / 1.35
HXTS800-XX-3-X DC-3GHz / ±1.5 ±2.0 ±2.5 / 1.4
HXTS800-XX-4-X DC-4GHz / ±2.0 ±2.5 ±3.0 / 1.5
