| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 3.2GHz | |
| ● | Pass Band Frequency | 2.9 ~ 3.5GHz | |
| ● | Pass Band Insertion Loss | ≤2.0dB | |
| ● | Pass Band VSWR | ≤1.3:1 | |
| ● | Stop Band Rejection | ≥60dB @ DC ~ 2.7GHz | ≥60dB @ 3.7 ~ 7.0GHz |
| ● | Impedance | 50 Ohms | |
| ● | Power | 5W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -20℃ ~ +60℃ | |
| Test Curve | |||
