| Technical Data Sheet | ||
| ● | Center Frequency(F0) | 1225MHz |
| ● | Pass Band Frequency | 950 ~ 1500MHz |
| ● | Pass Band Insertion Loss | ≤1.5dB |
| ● | Pass Band VSWR | ≤1.6:1 |
| ● | Stop Band Rejection | ≥30dB @ Fc±70MHz (DC ~ 880MHz、1570 ~ 2000MHz) |
| ● | Impedance | 50 Ohms |
| ● | Power | 10W Max. |
| ● | Connectors | SMA-Female |
| ● | Surface Finish | Painted Black |
| ● | Temperature Range | -30℃ ~ +70℃ |
| Test Curve | ||
