| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 172.3MHz | |
| ● | Pass Band Bandwidth | 170.3 ~ 174.3MHz | |
| ● | Pass Band Insertion Loss | ≤0.8dB | |
| ● | Pass Band VSWR | ≤1.5:1 | |
| ● | Stop Band Rejection | ≥60dB @ DC ~ 150.3MHz | ≥40dB @ 184.3 ~ 194.3MHz |
| ≥40dB @ 150.3 ~ 160.3MHz | ≥60dB @ 194.3 ~ 210MHz | ||
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 180W Max. | |
| ● | Connectors | N-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -20℃ ~ +65℃ | |
| Test Curve | |||
