| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 31.5GHz | |
| ● | Pass Band Frequency | 23 ~ 40GHz | |
| ● | Pass Band Insertion Loss | ≤1.1dB | |
| ● | Pass Band Ripple | ≤0.5dB | |
| ● | Pass Band Return Loss | ≥16dB | |
| ● | Stop Band Rejection | ≥80dB @ DC ~ 20.5GHz | ≥22dB @ 41 ~ 41.7GHz |
| ≥35dB @ 20.5 ~ 22GHz | ≥40dB @ 41.7 ~ 45GHz | ||
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 5W Max. | |
| ● | Connectors | 2.92mm(K)-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
