| Technical Data Sheet | |||
| S/N | Item | RX | TX |
| ● | Center Frequency(F0) | 1815MHz | 1865MHz |
| ● | Pass Band Bandwidth | 1800 ~ 1830MHz | 1850 ~ 1880MHz |
| ● | Pass Band Insertion Loss | ≤1.5dB | ≤1.5dB |
| ● | Pass Band Ripple | ≤0.7dB | ≤0.7dB |
| ● | Pass Band VSWR | ≤1.3:1 | ≤1.3:1 |
| ● | Stop Band Attenuation | ≥60dB @ 1850 ~ 1880MHz | ≥60dB @ 1800 ~ 1830MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power | 30W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Working Environment | Indoor | |
| Test Curve | |||
