| Technical Data Sheet | |||
| S/N | Item | RX | TX |
| 1 | Center Frequency(F0) | 917.5MHz | 926.5MHz |
| 2 | Pass Band Frequency | 915 ~ 920MHz | 925 ~ 928MHz |
| 3 | Pass Band Insertion Loss | ≤3.0dB | ≤3.0dB |
| 4 | Pass Band Ripple | ≤0.8dB | ≤0.5dB |
| 5 | Pass Band Return Loss | ≥18dB | ≥18dB |
| 6 | Stop Band Rejection | ≥40dB @ DC ~ 900MHz | ≥40dB @ DC ~ 910MHz |
| ≥20dB @ 925 ~ 935MHz | ≥20dB @ 910 ~ 920MHz | ||
| ≥40dB @ 935 ~ 2000MHz | ≥40dB @ 943 ~ 2000MHz | ||
| 7 | Impedance | 50 Ohms | |
| 8 | Power | 20W Max. | |
| 9 | Connectors | SMA-Female | |
| 10 | Surface Finish | Painted Black | |
| Test Curve | |||
