| Technical Data Sheet | ||||||
| P/N | Parameters | P1 | P2 | P3 | P4 | P5 |
| 1 | Frequency Range | 1800~2000MHz | 2300~2400MHz | 2500~2700MHz | 3400~3600MHz | 4800~5000MHz |
| 2 | Insertion Loss | ≤1.5dB | ≤1.6dB | ≤1.6dB | ≤1.5dB | ≤1.5dB |
| 3 | Stop Band Rejection | ≥50DB@2300-2700MHz | ≥50DB@1800-2000MHz | ≥50DB@1800-2400MHz | ≥70DB@1800-2700MHz | ≥70DB@1800-2700MHz |
| ≥70DB@3400-5000MHz | ≥50DB@2500-5000MHz | ≥70DB@3400-5000MHz | ≥70DB@4800-5000MHz | ≥50DB@3400-3600MHz | ||
| 4 | VSWR | ≤1.5:1 | ||||
| 5 | Power Handling | 30W Max | ||||
| 6 | Connectors | SMA-Female | ||||
| 7 | Ports Impedance | 50 Ohms | ||||
| 8 | Temperature | -20℃~+60℃ | ||||
| 9 | Surface Finish | Guide Oxygen | ||||
| Test Curve | ||||||
