Technical Data Sheet
●	Center Frequency(F0)	5.0GHz
●	3.0dB Pass Band Frequency	≈4.0～6.0GHz
●	1.0dB Pass Band Frequency	4.2～5.7GHz
●	Pass Band Insertion Loss	≤1.0dB
●	Pass Band VSWR	≤1.7:1
●	Stop Band Rejection	≥45dB @ DC～3.4GHz    ≥10dB @ 3.8GHz & 6.2GHz
		≥45dB @ 6.9～9.5GHz    ≥60dB @ 3.5GHz & 6.5GHz
●	Impedance	50 ohms
●	Power Handling	≤15W
●	Connectors	SMA-Female
Test Curve
