| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 6900MHz | |
| ● | Pass Band Frequency | 6450 ~ 7350MHz | |
| ● | Pass Band Insertion Loss | ≤1.5dB | |
| ● | Pass Band VSWR | ≤1.3:1 | |
| ● | Stop Band Attenuation | ≥30dB @ DC ~ 6300MHz | ≥30dB @ 7500 ~ 20000MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 5W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
