| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 725MHz | |
| ● | Pass Band Frequency | 600 ~ 850MHz | |
| ● | Pass Band Insertion Loss | ≤1.5dB @ 725MHz ≤2.0dB @ 600 ~ 850MHz | |
| ● | Pass Band VSWR | ≤1.5:1 | |
| ● | Stop Band Attenuation | ≥40dB @ DC ~ 500MHz | ≥40dB @ 950 ~ 1600MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 5.0W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Nickel Plating or Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
