| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 1300MHz | |
| ● | Pass Band Bandwidth | ±5.0MHz (1295 ~ 1305MHz) | |
| ● | Pass Band Insertion Loss | ≤2.0dB | |
| ● | Pass Band Ripple | ≤0.5dB | |
| ● | Pass Band VSWR | ≤1.3:1 | |
| ● | Stop Band Rejection | ≥30dB @ DC ~ 1280MHz | ≥30dB @ 1320 ~ 3500MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power | 20W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
