Technical Data Sheet
●	Center Frequency(F0)	1950MHz
●	Pass Band Frequency	1920 ~ 1980MHz
●	Pass Band Insertion Loss	≤2.0dB
●	Pass Band Ripple	≤0.9dB
●	Pass Band VSWR	≤1.22:1
●	Stop Band Rejection	≥40dB @ DC ~ 1900MHz	≥40dB @ 2000 ~ 4000MHz
●	Impedance	50 Ohms
●	Power	100W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
