Technical Data Sheet
●	Center Frequency(F0)	9.5GHz
●	Pass Band Frequency	9.0 ~ 10GHz
●	Pass Band Insertion Loss	≤0.7 dB
●	Pass Band Ripple	≤0.3dB
●	Pass Band Return Loss	≥20dB
●	Stop Band Rejection	≥80dB @ DC ~ 7.8GHz	≥70dB @ 11 ~ 11.2GHz
		≥70dB @ 7.8 ~ 8.0GHz	≥80dB @ 11.2 ~ 23GHz
●	Impedance	50 Ohms
●	Power Handling	10W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
