Technical Data Sheet
●	Center Frequency(F0)	6.2875GHz
●	Pass Band Frequency	5.85 ~ 6.725GHz
●	Pass Band Insertion Loss	≤0.6dB
●	Pass Band Ripple	≤0.2dB
●	Pass Band Return Loss	≥20dB
●	Stop Band Rejection	≥90dB @ DC ~ 4.6GHz	≥90dB @ 8.1 ~ 18.5GHz
●	Impedance	50 Ohms
●	Power Handling	20W Max.
●	Connectors	SMA-Female
●	Surface Finish	Painted Black
●	Temperature Range	-30℃ ~ +70℃
Test Curve
