| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 4185MHz | |
| ● | 3dB Bandwidth | 7.0MHz Max. (4181.5 ~ 4188.5MHz Max.) | |
| ● | Insertion Loss @ F0 | ≤6.5dB @ 4185MHz | |
| ● | Return Loss @ F0 | ≥18dB @ 4185MHz | |
| ● | Stop Band Rejection | ≥65dB @ DC ~ 4159.5MHz | ≥65dB @ 4210.5 ~ 8000MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power | 5.0W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | +15℃ ~ +30℃ | |
| Test Curve | |||
