| Technical Data Sheet | |||
| ● | Center Frequency(F0) | 2200MHz | |
| ● | 3.0dB Bandwidth | 1000MHz (1700 ~ 2700MHz) | |
| ● | Insertion Loss @ F0 | ≤1.0dB @ 2200MHz | |
| ● | Return Loss | ≥20dB @ 1800 ~ 2600MHz | |
| ● | Stop Band Rejection | ≥80dB @ DC ~ 1250MHz | ≥80dB @ 2900 ~ 6500MHz |
| ● | Impedance | 50 Ohms | |
| ● | Power Handling | 10W Max. | |
| ● | Connectors | SMA-Female | |
| ● | Surface Finish | Painted Black | |
| ● | Temperature Range | -30℃ ~ +70℃ | |
| Test Curve | |||
