| Technical Data Sheet | ||
| ● | Stop Band Frequency | 88 ~ 108MHz |
| ● | Stop Band Attenuation | ≥40dB |
| ● | Pass Band Frequency | DC ~ 78MHz , 120 ~ 200MHz |
| ● | Pass Band Insertion Loss | ≤1.5dB |
| ● | Pass Band VSWR | ≤1.5:1 |
| ● | Impedance | 50 Ohms |
| ● | Power Handling | 1.0W Max. |
| ● | Connectors | (SMA-Female Removable) |
| ● | Surface Finish | Housing: The Original Silver Color ; Cover: Guide Oxygen |
| ● | Temperature Range | -30℃ ~ +70℃ |
| Test Curve | ||
