| Technical Data Sheet | ||
| ● | Frequency Range | 150~300MHz |
| ● | Insertion Loss | ≤0.6dB(Excluding theoretical loss 3dB) |
| ● | Isolation | ≥20dB |
| ● | VSWR-Input | ≤1.20:1 |
| ● | VSWR-Output | ≤1.20:1 |
| ● | Amplitude Balance | ≤±0.3dB |
| ● | Phase Balance | ≤±3° |
| ● | Power Handling | Forward ≤50W(CW); Reversed ≤5W(CW) |
| ● | Impedance | 50Ω |
| ● | Port Connectors | N-Female |
| Test Curve | ||
