| Technical Data Sheet | ||
| ● | Center Frequency (F0) | 10.5GHz |
| ● | 1dB Bandwidth | 150MHz (10.425～10.575GHz) |
| ● | Insertion Loss at F0 | ≤0.5dB @ 10.5GHz |
| ● | Pass Band VSWR | ≤1.3:1 |
| ● | Stop Band Attenuation | ≥30dB @ F0±300MHz (10.2GHz、10.8GHz) |
| ≥60dB @ F0±600MHz (9.9GHz、11.1GHz) | ||
| ● | Impedance | 50 ohms |
| ● | Power Handling | ≤10W |
| ● | Connectors | SMA-Female |
| ● | Operating Temperature | -10℃～+60℃ |
| ● | Surface Finish | Black Paint |
| Test Curve | ||
