| Technical Data Sheet | ||
| ● | Center Frequency (F0) | 9840MHz |
| ● | Pass Band Frequency | 9800～9880MHz |
| ● | Pass Band Insertion Loss | ≤2.8dB |
| ● | Pass Band VSWR | ≤1.3:1 |
| ● | Stop Band Rejection | ≥30dB @ F0±80MHz |
| (DC～9760MHz、9920～15000MHz) | ||
| ● | Impedance | 50 ohms |
| ● | Power Handling | ≤5W |
| ● | Connectors | SMA-Female |
| ● | Surface Finish | Black Paint |
| ● | Temperature Range | 0℃～+40℃ |
| Test Curve | ||
