| Technical Data Sheet | ||
| ● | Center Frequency (F0) | 2500MHz |
| ● | Pass Band Frequency | 2497.5～2502.5MHz |
| ● | Pass Band Insertion Loss | ≤3.0dB |
| ● | Pass Band VSWR | ≤1.3:1 |
| ● | Stop Band Rejection | ≥50dB @ DC～2487.5MHz ≥50dB @ 2512.5～5000MHz |
| ● | Impedance | 50 ohms |
| ● | Power Handling | ≤10W |
| ● | Connectors | SMA-Female |
| ● | Surface Finish | Black Paint |
| ● | Temperature Range | -10℃～+60℃ |
| Test Curve | ||
