Technical Data Sheet
●	Center Frequency (F0)	600MHz
●	Pass Band Frequency	597～603MHz
●	Pass Band Insertion Loss	≤2.0dB
●	Pass Band VSWR	≤1.3:1
●	Stop Band Rejection	≥40dB @ DC～587MHz
		≥40dB @ 613～1500MHz
●	Impedance	50 ohms
●	Power Handling	≤20W
●	Connectors	SMA-Female
●	Surface Finish	Black Paint
●	Temperature Range	-30℃～+60℃
Test Curve
